<!DOCTYPE html>
<html lang="en">
<head>
<meta charset="UTF-8" />
<title>自己用自己的骰子，我大富翁和飞行棋无敌了！</title>
<style>
html,
body {
padding: 0;
margin: 0;
}
body {
height: 100vh;
display: flex;
align-items: end;
justify-content: center;
}
.container {
width: 100%;
height: 100%;
background-image: linear-gradient(#6dd5fa, #2980b9);
}
.lil-gui {
--width: 450px;
max-width: 90%;
--widget-height: 20px;
font-size: 15px;
--input-font-size: 15px;
--padding: 10px;
--spacing: 10px;
--slider-knob-width: 5px;
--background-color: rgba(5, 0, 15, 0.8);
--widget-color: rgba(255, 255, 255, 0.3);
--focus-color: rgba(255, 255, 255, 0.4);
--hover-color: rgba(255, 255, 255, 0.5);
--font-family: monospace;
}
</style>
</head>
<body>
<div class="container">
<canvas id="canvas"></canvas>
</div>
<script type="importmap">
{
"imports": {
"three": "https://unpkg.com/three@0.164.0/build/three.module.js",
"three/addons/": "https://unpkg.com/three@0.164.0/examples/jsm/"
}
}
</script>
<script
async
src="https://unpkg.com/es-module-shims@1.6.3/dist/es-module-shims.js"
></script>
<script type="module">
import * as CANNON from 'https://cdn.skypack.dev/cannon-es';
import * as THREE from 'three';
import * as BufferGeometryUtils from 'three/addons/utils/BufferGeometryUtils.js';
import GUI from 'https://cdn.jsdelivr.net/npm/lil-gui@0.18.2/+esm';
const containerEl = document.querySelector('.container');
const canvasEl = document.querySelector('#canvas');
let renderer, scene, camera, diceMesh, physicsRender, simulation;
let simulationOn = true;
let currentResult = [0, 0];
const params = {
segments: 40,
edgeRadius: 0.08,
notchRadius: 0.15,
notchDepth: 0.17,
restitution: 0.3,
friction: 0.1,
desiredResult: 7,
throw: throwMe,
};
function throwMe() {
simulationOn = true;
throwDice();
}
const diceArray = [];
const floorPlanesArray = [];
let throwBtn;
initPhysics();
initScene();
createFloor();
diceMesh = createDiceMesh();
for (let i = 0; i < 2; i++) {
diceArray.push(createDice());
addDiceEvents(diceArray[i], i);
}
createControls();
throwMe();
render();
window.addEventListener('resize', updateSceneSize);
window.addEventListener('click', () => {});
function initScene() {
renderer = new THREE.WebGLRenderer({
alpha: true,
antialias: true,
canvas: canvasEl,
});
renderer.shadowMap.enabled = true;
renderer.setPixelRatio(Math.min(window.devicePixelRatio, 2));
scene = new THREE.Scene();
camera = new THREE.PerspectiveCamera(
45,
containerEl.clientWidth / containerEl.clientHeight,
0.1,
100
);
camera.position.set(0, 9, 12);
camera.lookAt(0, 4, 0);
updateSceneSize();
const ambientLight = new THREE.AmbientLight(0xffffff, 1);
scene.add(ambientLight);
const light = new THREE.PointLight(0xffffff, 1000);
light.position.set(10, 20, 5);
light.castShadow = true;
light.shadow.mapSize.width = 2048;
light.shadow.mapSize.height = 2048;
scene.add(light);
}
function initPhysics() {
const gravity = new CANNON.Vec3(0, -50, 0);
const allowSleep = true;
physicsRender = new CANNON.World({
allowSleep,
gravity,
});
simulation = new CANNON.World({
allowSleep,
gravity,
});
physicsRender.defaultContactMaterial.restitution = params.restitution;
simulation.defaultContactMaterial.restitution = params.restitution;
physicsRender.defaultContactMaterial.friction = params.friction;
simulation.defaultContactMaterial.friction = params.friction;
}
function createFloor() {
for (let i = 0; i < 4; i++) {
const body = new CANNON.Body({
type: CANNON.Body.STATIC,
shape: new CANNON.Plane(),
});
physicsRender.addBody(body);
simulation.addBody(body);
let mesh;
if (i === 0) {
mesh = new THREE.Mesh(
new THREE.PlaneGeometry(100, 100, 100, 100),
new THREE.ShadowMaterial({
opacity: 0.1,
})
);
scene.add(mesh);
mesh.receiveShadow = true;
}
floorPlanesArray.push({
body,
mesh,
});
}
floorPositionUpdate();
}
function floorPositionUpdate() {
floorPlanesArray.forEach((f, fIdx) => {
if (fIdx === 0) {
f.body.position.y = 0;
f.body.quaternion.setFromEuler(-0.5 * Math.PI, 0, 0);
} else if (fIdx === 1) {
f.body.quaternion.setFromEuler(0, 0.5 * Math.PI, 0);
f.body.position.x =
(-6 * containerEl.clientWidth) / containerEl.clientHeight;
} else if (fIdx === 2) {
f.body.quaternion.setFromEuler(0, -0.5 * Math.PI, 0);
f.body.position.x =
(6 * containerEl.clientWidth) / containerEl.clientHeight;
} else if (fIdx === 3) {
f.body.quaternion.setFromEuler(0, Math.PI, 0);
f.body.position.z = 3;
}
if (f.mesh) {
f.mesh.position.copy(f.body.position);
f.mesh.quaternion.copy(f.body.quaternion);
}
});
}
function createDiceMesh() {
const boxMaterialOuter = new THREE.MeshStandardMaterial({
color: 0xffffff,
});
const boxMaterialInner = new THREE.MeshStandardMaterial({
color: 0x000000,
roughness: 0,
metalness: 1,
});
const g = new THREE.Group();
const innerSide = 1 - params.edgeRadius;
const innerMesh = new THREE.Mesh(
new THREE.BoxGeometry(innerSide, innerSide, innerSide),
boxMaterialInner
);
const outerMesh = new THREE.Mesh(createBoxGeometry(), boxMaterialOuter);
outerMesh.castShadow = true;
g.add(innerMesh, outerMesh);
return g;
}
function createDice() {
const mesh = diceMesh.clone();
scene.add(mesh);
const shape = new CANNON.Box(new CANNON.Vec3(0.5, 0.5, 0.5));
const mass = 1;
const sleepTimeLimit = 0.02;
const body = new CANNON.Body({
mass,
shape,
sleepTimeLimit,
});
physicsRender.addBody(body);
const simulationBody = new CANNON.Body({
mass,
shape,
sleepTimeLimit,
});
simulation.addBody(simulationBody);
return {
mesh,
body: [body, simulationBody],
startPos: [null, null, null],
};
}
function createBoxGeometry() {
let boxGeometry = new THREE.BoxGeometry(
1,
1,
1,
params.segments,
params.segments,
params.segments
);
const positionAttr = boxGeometry.attributes.position;
const subCubeHalfSize = 0.5 - params.edgeRadius;
const notchWave = (v) => {
v = (1 / params.notchRadius) * v;
v = Math.PI * Math.max(-1, Math.min(1, v));
return params.notchDepth * (Math.cos(v) + 1);
};
const notch = (pos) => notchWave(pos[0]) * notchWave(pos[1]);
for (let i = 0; i < positionAttr.count; i++) {
let position = new THREE.Vector3().fromBufferAttribute(
positionAttr,
i
);
const subCube = new THREE.Vector3(
Math.sign(position.x),
Math.sign(position.y),
Math.sign(position.z)
).multiplyScalar(subCubeHalfSize);
const addition = new THREE.Vector3().subVectors(position, subCube);
if (
Math.abs(position.x) > subCubeHalfSize &&
Math.abs(position.y) > subCubeHalfSize &&
Math.abs(position.z) > subCubeHalfSize
) {
addition.normalize().multiplyScalar(params.edgeRadius);
position = subCube.add(addition);
} else if (
Math.abs(position.x) > subCubeHalfSize &&
Math.abs(position.y) > subCubeHalfSize
) {
addition.z = 0;
addition.normalize().multiplyScalar(params.edgeRadius);
position.x = subCube.x + addition.x;
position.y = subCube.y + addition.y;
} else if (
Math.abs(position.x) > subCubeHalfSize &&
Math.abs(position.z) > subCubeHalfSize
) {
addition.y = 0;
addition.normalize().multiplyScalar(params.edgeRadius);
position.x = subCube.x + addition.x;
position.z = subCube.z + addition.z;
} else if (
Math.abs(position.y) > subCubeHalfSize &&
Math.abs(position.z) > subCubeHalfSize
) {
addition.x = 0;
addition.normalize().multiplyScalar(params.edgeRadius);
position.y = subCube.y + addition.y;
position.z = subCube.z + addition.z;
}
const offset = 0.23;
if (position.y === 0.5) {
position.y -= notch([position.x, position.z]);
} else if (position.x === 0.5) {
position.x -= notch([position.y + offset, position.z + offset]);
position.x -= notch([position.y - offset, position.z - offset]);
} else if (position.z === 0.5) {
position.z -= notch([position.x - offset, position.y + offset]);
position.z -= notch([position.x, position.y]);
position.z -= notch([position.x + offset, position.y - offset]);
} else if (position.z === -0.5) {
position.z += notch([position.x + offset, position.y + offset]);
position.z += notch([position.x + offset, position.y - offset]);
position.z += notch([position.x - offset, position.y + offset]);
position.z += notch([position.x - offset, position.y - offset]);
} else if (position.x === -0.5) {
position.x += notch([position.y + offset, position.z + offset]);
position.x += notch([position.y + offset, position.z - offset]);
position.x += notch([position.y, position.z]);
position.x += notch([position.y - offset, position.z + offset]);
position.x += notch([position.y - offset, position.z - offset]);
} else if (position.y === -0.5) {
position.y += notch([position.x + offset, position.z + offset]);
position.y += notch([position.x + offset, position.z]);
position.y += notch([position.x + offset, position.z - offset]);
position.y += notch([position.x - offset, position.z + offset]);
position.y += notch([position.x - offset, position.z]);
position.y += notch([position.x - offset, position.z - offset]);
}
positionAttr.setXYZ(i, position.x, position.y, position.z);
}
boxGeometry.deleteAttribute('normal');
boxGeometry.deleteAttribute('uv');
boxGeometry = BufferGeometryUtils.mergeVertices(boxGeometry);
boxGeometry.computeVertexNormals();
return boxGeometry;
}
function addDiceEvents(dice, diceIdx) {
dice.body.forEach((b) => {
b.addEventListener('sleep', (e) => {
b.allowSleep = false;
if (simulationOn) {
const euler = new CANNON.Vec3();
e.target.quaternion.toEuler(euler);
const eps = 0.1;
let isZero = (angle) => Math.abs(angle) < eps;
let isHalfPi = (angle) => Math.abs(angle - 0.5 * Math.PI) < eps;
let isMinusHalfPi = (angle) =>
Math.abs(0.5 * Math.PI + angle) < eps;
let isPiOrMinusPi = (angle) =>
Math.abs(Math.PI - angle) < eps ||
Math.abs(Math.PI + angle) < eps;
if (isZero(euler.z)) {
if (isZero(euler.x)) {
currentResult[diceIdx] = 1;
} else if (isHalfPi(euler.x)) {
currentResult[diceIdx] = 4;
} else if (isMinusHalfPi(euler.x)) {
currentResult[diceIdx] = 3;
} else if (isPiOrMinusPi(euler.x)) {
currentResult[diceIdx] = 6;
} else {
b.allowSleep = true;
throwDice();
}
} else if (isHalfPi(euler.z)) {
currentResult[diceIdx] = 2;
} else if (isMinusHalfPi(euler.z)) {
currentResult[diceIdx] = 5;
} else {
b.allowSleep = true;
throwDice();
}
const thisDiceRes = currentResult[diceIdx];
const anotherDiceRes = currentResult[diceIdx ? 0 : 1];
const currentSum = currentResult.reduce((a, v) => a + v, 0);
if (anotherDiceRes === 0 && thisDiceRes >= params.desiredResult) {
throwDice();
} else if (anotherDiceRes !== 0) {
if (params.desiredResult !== currentSum) {
throwDice();
} else {
simulationOn = false;
throwBtn.innerHTML = 'throw!';
throwDice();
}
}
}
});
});
}
function render() {
if (simulationOn) {
simulation.step(1 / 60, 5000, 60);
} else {
physicsRender.fixedStep();
for (const dice of diceArray) {
dice.mesh.position.copy(dice.body[0].position);
dice.mesh.quaternion.copy(dice.body[0].quaternion);
}
renderer.render(scene, camera);
}
requestAnimationFrame(render);
}
function updateSceneSize() {
camera.aspect = containerEl.clientWidth / containerEl.clientHeight;
camera.updateProjectionMatrix();
renderer.setSize(containerEl.clientWidth, containerEl.clientHeight);
floorPositionUpdate();
}
function throwDice() {
const quaternion = new THREE.Quaternion();
if (simulationOn) {
throwBtn.innerHTML = 'calculating a throw...';
currentResult = [0, 0];
diceArray.forEach((d) => {
d.startPos = [Math.random(), Math.random(), Math.random()];
});
}
diceArray.forEach((d, dIdx) => {
quaternion.setFromEuler(
new THREE.Euler(
2 * Math.PI * d.startPos[0],
0,
2 * Math.PI * d.startPos[1]
)
);
const force = 6 + 3 * d.startPos[2];
const b = simulationOn ? d.body[1] : d.body[0];
b.position = new CANNON.Vec3(3, 5 + dIdx, 2);
b.velocity.setZero();
b.angularVelocity.setZero();
b.applyImpulse(
new CANNON.Vec3(-force, force, 0),
new CANNON.Vec3(0, 0, -0.5)
);
b.quaternion.copy(quaternion);
b.allowSleep = true;
});
}
function createControls() {
const gui = new GUI();
gui.add(params, 'desiredResult', 2, 12, 1).name('result');
const btnControl = gui.add(params, 'throw').name('throw!');
throwBtn = btnControl.domElement.querySelector('button > .name');
}
</script>
</body>
</html>
